Unpaired Electrons In Complex Ions A CFT Explanation For $ML_6^{n+}$

When dealing with coordination complexes, understanding their electronic structure and magnetic properties requires delving into crystal field theory (CFT). This theory helps us predict how the interaction between metal ions and ligands affects the d-orbital energies, ultimately dictating the number of unpaired electrons and the complex's magnetic behavior. So, let's consider the specific scenario presented: a complex ion $ML_6^{n+}$, where $M^{n+}$ possesses four d-electrons and L represents a strong field ligand. Our primary objective is to determine the number of unpaired electrons present in this complex, which will then shed light on its magnetic properties.

Crystal Field Theory: A Foundation for Understanding

At its core, crystal field theory (CFT) elucidates the interaction between a central metal ion and the surrounding ligands as primarily electrostatic. Ligands, which are molecules or ions with lone pairs of electrons, create an electrostatic field that perturbs the energies of the metal ion's d-orbitals. The fundamental principle is that the five d-orbitals, which are degenerate (possessing the same energy) in an isolated metal ion, experience energy splitting when placed in the ligand field. This splitting pattern and magnitude depend on the geometry of the complex and the nature of the ligands.

Octahedral Complexes and d-Orbital Splitting

In an octahedral complex, such as $ML_6^{n+}$, the six ligands approach the central metal ion along the Cartesian axes (x, y, and z). This arrangement results in a characteristic splitting pattern for the d-orbitals. The five d-orbitals divide into two sets with distinct energy levels: the $t_{2g}$ set (comprising $d_{xy}$, $d_{xz}$, and $d_{yz}$ orbitals) and the $e_g$ set (comprising $d_{x^2-y^2}$ and $d_{z^2}$ orbitals). The $e_g$ orbitals, which point directly toward the ligands, experience greater electrostatic repulsion and thus reside at a higher energy level than the $t_{2g}$ orbitals, which point between the ligands. The energy difference between these two sets is denoted as Δo (the crystal field splitting energy).

Strong-Field Ligands and Low-Spin Complexes

The magnitude of Δo is dictated by the nature of the ligands. Strong-field ligands, such as cyanide ($CN^−$) and carbon monoxide (CO), induce a large crystal field splitting, resulting in a significant energy gap between the $t_{2g}$ and $e_g$ levels. This large splitting energy influences the way d-electrons populate the orbitals. In strong-field complexes, electrons preferentially pair up in the lower-energy $t_{2g}$ orbitals before occupying the higher-energy $e_g$ orbitals. This electron configuration leads to the formation of low-spin complexes, which exhibit a minimal number of unpaired electrons.

Applying CFT to the Complex Ion $ML_6^{n+}$

Now, let's apply these principles to the specific complex ion in question, $ML_6^{n+}$. We are given that the metal ion, $M^{n+}$, has four d-electrons, and the ligand, L, is a strong-field ligand. Our goal is to determine the electronic configuration and the number of unpaired electrons. Since L is a strong-field ligand, it induces a large crystal field splitting (Δo). This means that the energy gap between the $t_{2g}$ and $e_g$ orbitals is significant.

Filling the d-Orbitals: The Low-Spin Configuration

Following Hund's rule, electrons individually occupy orbitals within a subshell before pairing up. However, in this case, the large Δo dictates that electrons will first fill the lower-energy $t_{2g}$ orbitals before occupying the $e_g$ orbitals. With four d-electrons, the first three electrons will individually occupy the three $t_{2g}$ orbitals ($d_{xy}$, $d_{xz}$, and $d_{yz}$). The fourth electron will then pair up with one of the electrons in the $t_{2g}$ set, as it requires less energy to pair up in the $t_{2g}$ orbitals than to occupy one of the higher-energy $e_g$ orbitals.

Determining the Number of Unpaired Electrons

The resulting electronic configuration is $t_{2g}^4 e_g^0$. This signifies that all four d-electrons reside in the $t_{2g}$ orbitals, with two of these orbitals containing paired electrons and the third containing two electrons. Consequently, there are two unpaired electrons in the complex ion. This low-spin configuration arises due to the strong field ligand forcing electron pairing in the lower energy orbitals.

Magnetic Properties and Unpaired Electrons

The number of unpaired electrons directly influences the magnetic properties of a complex ion. Substances with unpaired electrons exhibit paramagnetism, meaning they are attracted to an external magnetic field. The strength of the paramagnetic effect is proportional to the number of unpaired electrons. Conversely, substances with all paired electrons are diamagnetic and are weakly repelled by a magnetic field.

The $ML_6^{n+}$ Complex: A Paramagnetic Species

Since the complex ion $ML_6^{n+}$ possesses two unpaired electrons, it is paramagnetic. This means that the complex will be attracted to an external magnetic field. The magnitude of this attraction can be experimentally measured, providing valuable information about the electronic structure and the number of unpaired electrons in the complex.

Conclusion: Unraveling Magnetic Properties Through CFT

In summary, by applying crystal field theory, we have successfully determined the number of unpaired electrons in the complex ion $ML_6^{n+}$. The strong-field nature of the ligand L leads to a low-spin configuration, resulting in two unpaired electrons. This understanding allows us to predict that the complex ion will exhibit paramagnetism. Crystal field theory serves as a powerful tool for understanding the electronic structure, bonding, and magnetic properties of coordination complexes, playing a crucial role in various fields, including inorganic chemistry, materials science, and catalysis.

Therefore, the correct answer is 3) 2.

Based on crystal field theory, how many unpaired electrons are there in the complex ion $ML_6^{n+}$ if $M^{n+}$ has four d-electrons and L is a strong field ligand?
