In the realm of mathematical logic, understanding logical equivalences and normal forms is crucial for simplifying complex expressions and reasoning about them effectively. This article delves into two main problems. First, we explore the logical equivalence of propositional statements using truth tables and logical transformations. Specifically, we aim to demonstrate that ¬(P ∧ Q) → (¬P ∨ (¬P ∨ Q)) is equivalent to (¬P ∨ Q), and (P ∨ Q) ∧ (¬P ∧ (¬P ∧ Q)) is equivalent to (¬P ∧ Q). Second, we tackle the conversion of a logical formula into its principal conjunctive normal form (PCNF), which is a standardized way of representing logical statements. We will focus on the formula S given by (¬(P → R) ∧ (Q ↔ P)) and derive its PCNF.

Part 1: Demonstrating Logical Equivalences

Problem 1: ¬(P ∧ Q) → (¬P ∨ (¬P ∨ Q)) ⇔ (¬P ∨ Q)

In this first problem, our objective is to prove that the logical statement ¬(P ∧ Q) → (¬P ∨ (¬P ∨ Q)) is logically equivalent to (¬P ∨ Q). To achieve this, we will employ two primary methods: constructing a truth table and using logical transformations. The truth table method involves evaluating the truth values of both statements for all possible combinations of truth values for the propositional variables P and Q. If the truth values match for all combinations, the statements are logically equivalent. Logical transformations, on the other hand, involve applying a series of logical equivalences (such as De Morgan's laws, distribution, and implication equivalences) to one statement to transform it into the other.

Method 1: Truth Table

To construct a truth table, we need to consider all possible combinations of truth values for the propositional variables P and Q. These combinations are (P=True, Q=True), (P=True, Q=False), (P=False, Q=True), and (P=False, Q=False). For each combination, we evaluate the truth values of the expressions ¬(P ∧ Q) → (¬P ∨ (¬P ∨ Q)) and (¬P ∨ Q). If the truth values match for all combinations, we can conclude that the statements are logically equivalent.

Let's begin by constructing the truth table:

P	Q	P ∧ Q	¬(P ∧ Q)	¬P	¬P ∨ Q	¬P ∨ (¬P ∨ Q)	¬(P ∧ Q) → (¬P ∨ (¬P ∨ Q))	¬P ∨ Q
True	True	True	False	False	True	True	True	True
True	False	False	True	False	False	False	False	False
False	True	False	True	True	True	True	True	True
False	False	False	True	True	True	True	True	True

As observed from the truth table, the truth values of ¬(P ∧ Q) → (¬P ∨ (¬P ∨ Q)) and (¬P ∨ Q) are identical for all possible combinations of P and Q. Therefore, we can conclusively state that the two logical statements are logically equivalent.

Method 2: Logical Transformations

Now, let's demonstrate the equivalence using logical transformations. We will start with the left-hand side of the equivalence, ¬(P ∧ Q) → (¬P ∨ (¬P ∨ Q)), and apply logical equivalences to transform it into the right-hand side, (¬P ∨ Q). This process involves using well-established logical laws and identities, such as De Morgan's laws, the implication equivalence, the associative law, and the identity law.

Implication Equivalence: A → B ≡ ¬A ∨ B

Applying the implication equivalence to the original statement, we get:
```
¬(P ∧ Q) → (¬P ∨ (¬P ∨ Q)) ≡ ¬(¬(P ∧ Q)) ∨ (¬P ∨ (¬P ∨ Q))
```
Double Negation: ¬(¬A) ≡ A

Applying the double negation law, we simplify the expression:
```
¬(¬(P ∧ Q)) ∨ (¬P ∨ (¬P ∨ Q)) ≡ (P ∧ Q) ∨ (¬P ∨ (¬P ∨ Q))
```
Associative Law: A ∨ (B ∨ C) ≡ (A ∨ B) ∨ C

Using the associative law, we can regroup the terms:
```
(P ∧ Q) ∨ (¬P ∨ (¬P ∨ Q)) ≡ (P ∧ Q) ∨ ((¬P ∨ ¬P) ∨ Q)
```
Idempotent Law: A ∨ A ≡ A

Applying the idempotent law, we simplify the expression further:
```
(P ∧ Q) ∨ ((¬P ∨ ¬P) ∨ Q) ≡ (P ∧ Q) ∨ (¬P ∨ Q)
```
De Morgan's Law: ¬(P ∧ Q) ≡ ¬P ∨ ¬Q

However, instead of directly using De Morgan's law, let's consider the distribution and simplification differently to arrive at the result efficiently.
Distribution and Simplification We can rewrite the expression as:

(P ∧ Q) ∨ (¬P ∨ Q) ≡ ((P ∧ Q) ∨ ¬P) ∨ Q

Distribution Apply the distributive law:

((P ∧ Q) ∨ ¬P) ∨ Q ≡ ((P ∨ ¬P) ∧ (Q ∨ ¬P)) ∨ Q

Complement Law: P ∨ ¬P ≡ True

((P ∨ ¬P) ∧ (Q ∨ ¬P)) ∨ Q ≡ (True ∧ (Q ∨ ¬P)) ∨ Q

Identity Law: True ∧ A ≡ A

(True ∧ (Q ∨ ¬P)) ∨ Q ≡ (Q ∨ ¬P) ∨ Q

Associative Law and Idempotent Law

(Q ∨ ¬P) ∨ Q ≡ ¬P ∨ (Q ∨ Q) ≡ ¬P ∨ Q

Thus, by applying logical transformations, we have successfully shown that ¬(P ∧ Q) → (¬P ∨ (¬P ∨ Q)) is equivalent to ¬P ∨ Q. This equivalence demonstrates the simplification and manipulation of logical statements through established laws and identities, reinforcing the importance of these tools in logical reasoning and problem-solving.

Problem 2: (P ∨ Q) ∧ (¬P ∧ (¬P ∧ Q)) ⇔ (¬P ∧ Q)

For the second equivalence problem, we aim to prove that the logical statement (P ∨ Q) ∧ (¬P ∧ (¬P ∧ Q)) is logically equivalent to (¬P ∧ Q). Similar to the previous problem, we will utilize both truth tables and logical transformations to establish this equivalence. The truth table method allows us to exhaustively check all possible truth value combinations for the variables P and Q, while logical transformations provide a step-by-step algebraic approach to manipulate the expressions and arrive at the desired equivalence.

Method 1: Truth Table

We will construct a truth table to evaluate the truth values of both sides of the equivalence for all possible combinations of P and Q. This involves evaluating (P ∨ Q) ∧ (¬P ∧ (¬P ∧ Q)) and (¬P ∧ Q) for the cases where (P=True, Q=True), (P=True, Q=False), (P=False, Q=True), and (P=False, Q=False). If the resulting truth values match for each combination, we can confirm the equivalence.

Let's construct the truth table:

P	Q	P ∨ Q	¬P	¬P ∧ Q	¬P ∧ (¬P ∧ Q)	(P ∨ Q) ∧ (¬P ∧ (¬P ∧ Q))	¬P ∧ Q
True	True	True	False	False	False	False	False
True	False	True	False	False	False	False	False
False	True	True	True	True	True	True	True
False	False	False	True	False	False	False	False

The truth table shows that the columns for (P ∨ Q) ∧ (¬P ∧ (¬P ∧ Q)) and (¬P ∧ Q) have identical truth values for all combinations of P and Q. This confirms that the two statements are logically equivalent.

Method 2: Logical Transformations

Next, we will use logical transformations to demonstrate the equivalence algebraically. We will start with the left-hand side of the equivalence, (P ∨ Q) ∧ (¬P ∧ (¬P ∧ Q)), and apply logical equivalences to simplify it and transform it into the right-hand side, (¬P ∧ Q). This process requires the strategic application of logical laws such as the associative law, the idempotent law, and the distributive law.

Associative Law: A ∧ (B ∧ C) ≡ (A ∧ B) ∧ C

Applying the associative law, we regroup the terms:
```
(P ∨ Q) ∧ (¬P ∧ (¬P ∧ Q)) ≡ (P ∨ Q) ∧ ((¬P ∧ ¬P) ∧ Q)
```
Idempotent Law: A ∧ A ≡ A

Using the idempotent law, we simplify the expression:
```
(P ∨ Q) ∧ ((¬P ∧ ¬P) ∧ Q) ≡ (P ∨ Q) ∧ (¬P ∧ Q)
```
Distributive Law: A ∧ (B ∧ C) ≡ (A ∧ B) ∧ C

Apply the distributive law. It can also be viewed as Associativity
```
(P ∨ Q) ∧ (¬P ∧ Q) ≡ ((P ∨ Q) ∧ ¬P) ∧ Q
```
Distributive Law: (A ∨ B) ∧ C ≡ (A ∧ C) ∨ (B ∧ C)

Apply the distributive law again
```
((P ∨ Q) ∧ ¬P) ∧ Q ≡ ((P ∧ ¬P) ∨ (Q ∧ ¬P)) ∧ Q
```
Complement Law: P ∧ ¬P ≡ False

Applying the complement law, we further simplify:
```
((P ∧ ¬P) ∨ (Q ∧ ¬P)) ∧ Q ≡ (False ∨ (Q ∧ ¬P)) ∧ Q
```
Identity Law: False ∨ A ≡ A

Using the identity law, we get:
```
(False ∨ (Q ∧ ¬P)) ∧ Q ≡ (Q ∧ ¬P) ∧ Q
```
Associative Law: (A ∧ B) ∧ C ≡ A ∧ (B ∧ C)

Apply associative law one more time.
```
(Q ∧ ¬P) ∧ Q ≡ Q ∧ (¬P ∧ Q)
```
Commutative Law: A ∧ B ≡ B ∧ A

Using the commutative law, we obtain

```
Q ∧ (¬P ∧ Q) ≡  Q ∧ (Q ∧ ¬P)
```

Associative Law:

Q ∧ (Q ∧ ¬P) ≡ (Q ∧ Q) ∧ ¬P

Idempotent Law: A ∧ A ≡ A

(Q ∧ Q) ∧ ¬P ≡ Q ∧ ¬P

Commutative Law: A ∧ B ≡ B ∧ A

Finally, we rearrange the terms to match the right-hand side:
```
Q ∧ ¬P ≡ ¬P ∧ Q
```

By employing these logical transformations, we have successfully transformed the left-hand side of the equivalence into the right-hand side, thereby proving that (P ∨ Q) ∧ (¬P ∧ (¬P ∧ Q)) is indeed logically equivalent to (¬P ∧ Q). This demonstration highlights the power of algebraic manipulation in simplifying and understanding complex logical expressions.

Part 2: Principal Conjunctive Normal Form (PCNF)

Problem: Obtain the Principal Conjunctive Normal Form of S given by (¬(P → R) ∧ (Q ↔ P))

In this section, we address the problem of converting a logical formula into its principal conjunctive normal form (PCNF). The PCNF, also known as the maxterm canonical form, is a standard way of representing logical statements as a conjunction (AND) of maxterms. A maxterm is a disjunction (OR) of literals, where a literal is either a propositional variable or its negation. The PCNF is particularly useful in automated theorem proving and digital circuit design.

Our task is to find the PCNF of the formula S given by (¬(P → R) ∧ (Q ↔ P)). This involves a series of steps, including eliminating implications and biconditionals, applying De Morgan's laws, using the distributive law, and finally, expressing the formula as a conjunction of maxterms. Each maxterm should include all the propositional variables present in the formula, which in this case are P, Q, and R.

Step 1: Eliminate Implications and Biconditionals

The first step is to eliminate the implication (→) and biconditional (↔) connectives. We will use the following logical equivalences:

Implication Equivalence: A → B ≡ ¬A ∨ B
Biconditional Equivalence: A ↔ B ≡ (A → B) ∧ (B → A)

Applying these equivalences to our formula S, we get:

S = (¬(P → R) ∧ (Q ↔ P))
  ≡ (¬(¬P ∨ R) ∧ ((Q → P) ∧ (P → Q)))
  ≡ (¬(¬P ∨ R) ∧ ((¬Q ∨ P) ∧ (¬P ∨ Q)))

Step 2: Apply De Morgan's Laws

Next, we apply De Morgan's laws to eliminate the negation of the disjunction:

De Morgan's Law: ¬(A ∨ B) ≡ ¬A ∧ ¬B

Applying De Morgan's law to the first part of the expression, we have:

S ≡ ((¬(¬P) ∧ ¬R) ∧ ((¬Q ∨ P) ∧ (¬P ∨ Q)))
  ≡ ((P ∧ ¬R) ∧ ((¬Q ∨ P) ∧ (¬P ∨ Q)))

Step 3: Apply the Distributive Law

Now, we apply the distributive law to convert the expression into a conjunctive normal form (CNF). The distributive law states:

Distributive Law: A ∧ (B ∨ C) ≡ (A ∧ B) ∨ (A ∧ C)
Distributive Law: (A ∨ B) ∧ C ≡ (A ∧ C) ∨ (B ∧ C)

However, we need to apply it in reverse to transform the expression into a conjunction of disjunctions. First, we'll distribute (P ∧ ¬R) across the remaining terms:

S ≡ (P ∧ ¬R) ∧ ((¬Q ∨ P) ∧ (¬P ∨ Q))
  ≡ (P ∧ ¬R) ∧ ((¬Q ∨ P) ∧ (¬P ∨ Q))
  ≡ (P ∧ ¬R) ∧ ((¬Q ∧ (¬P ∨ Q)) ∨ (P ∧ (¬P ∨ Q)))

Further distributing:

S ≡ (P ∧ ¬R) ∧ ((¬Q ∧ ¬P) ∨ (¬Q ∧ Q) ∨ (P ∧ ¬P) ∨ (P ∧ Q))

Step 4: Simplify Using Logical Identities

We can simplify the expression using the following logical identities:

Complement Law: A ∧ ¬A ≡ False
Identity Law: A ∨ False ≡ A

Applying these identities, we get:

S ≡ (P ∧ ¬R) ∧ ((¬Q ∧ ¬P) ∨ False ∨ False ∨ (P ∧ Q))
  ≡ (P ∧ ¬R) ∧ ((¬Q ∧ ¬P) ∨ (P ∧ Q))

Now, distribute (P ∧ ¬R) across ((¬Q ∧ ¬P) ∨ (P ∧ Q)):

S ≡ ((P ∧ ¬R) ∧ (¬Q ∧ ¬P)) ∨ ((P ∧ ¬R) ∧ (P ∧ Q))

Applying Associative Law and Commutative Law:

S ≡ (P ∧ ¬R ∧ ¬Q ∧ ¬P) ∨ (P ∧ ¬R ∧ P ∧ Q)

Further simplification with Idempotent and Commutative Laws:

S ≡ (P ∧ ¬P ∧ ¬Q ∧ ¬R) ∨ (P ∧ Q ∧ ¬R)

Applying Complement Law:

S ≡ (False ∧ ¬Q ∧ ¬R) ∨ (P ∧ Q ∧ ¬R)
S ≡ False ∨ (P ∧ Q ∧ ¬R)

Applying Identity Law:

S ≡ P ∧ Q ∧ ¬R

Step 5: Convert to Conjunctive Normal Form (CNF)

Since our expression is now a conjunction of literals, we need to convert it into a disjunction of maxterms. We do this by adding the missing variables to each term. To convert to PCNF, we first write S in CNF, and then convert it to PCNF.

The expression P ∧ Q ∧ ¬R is already in a simplified form. However, to find the PCNF, we need to express it as a conjunction of maxterms involving all three variables P, Q, and R. We can do this by converting S ≡ P ∧ Q ∧ ¬R to its equivalent maxterm form.

To find the PCNF, we look for the minterms (combinations) that make the expression true. The expression P ∧ Q ∧ ¬R is true when P is true, Q is true, and R is false. This corresponds to the minterm P ∧ Q ∧ ¬R.

Therefore, the formula is true only for one combination (1, 1, 0). To convert this to PCNF, we need to identify all the combinations that make the formula false and express them as maxterms (disjunctions).

The maxterms are the complements of the minterms. Since we have only one minterm that makes the expression true, we can represent this in PCNF by listing all the combinations that make the expression false.

Combinations that make the expression false are:

(P=0, Q=0, R=0) : ¬P ∧ ¬Q ∧ R, Maxterm: P ∨ Q ∨ R
(P=0, Q=0, R=1) : ¬P ∧ ¬Q ∧ ¬R, Maxterm: P ∨ Q ∨ ¬R
(P=0, Q=1, R=0) : ¬P ∧ Q ∧ R, Maxterm: P ∨ ¬Q ∨ R
(P=0, Q=1, R=1) : ¬P ∧ Q ∧ ¬R, Maxterm: P ∨ ¬Q ∨ ¬R
(P=1, Q=0, R=0) : P ∧ ¬Q ∧ R, Maxterm: ¬P ∨ Q ∨ R
(P=1, Q=0, R=1) : P ∧ ¬Q ∧ ¬R, Maxterm: ¬P ∨ Q ∨ ¬R
(P=1, Q=1, R=1) : P ∧ Q ∧ R, Maxterm: ¬P ∨ ¬Q ∨ ¬R

Step 6: Construct the PCNF

The PCNF is the conjunction (AND) of all these maxterms:

S_PCNF = (P ∨ Q ∨ R) ∧ (P ∨ Q ∨ ¬R) ∧ (P ∨ ¬Q ∨ R) ∧ (P ∨ ¬Q ∨ ¬R) ∧ (¬P ∨ Q ∨ R) ∧ (¬P ∨ Q ∨ ¬R) ∧ (¬P ∨ ¬Q ∨ ¬R)

This is the principal conjunctive normal form (PCNF) of the given formula S.

Conclusion

In summary, we have successfully demonstrated logical equivalences using truth tables and logical transformations. For the first problem, we proved that ¬(P ∧ Q) → (¬P ∨ (¬P ∨ Q)) is logically equivalent to (¬P ∨ Q), and for the second problem, we showed that (P ∨ Q) ∧ (¬P ∧ (¬P ∧ Q)) is logically equivalent to (¬P ∧ Q). Furthermore, we derived the principal conjunctive normal form (PCNF) for the formula S given by (¬(P → R) ∧ (Q ↔ P)). The PCNF, expressed as the conjunction of maxterms, provides a standardized representation of logical statements that is essential in various applications within computer science and mathematics. These exercises underscore the importance of logical reasoning, simplification techniques, and normal forms in the field of mathematical logic.
