Graphing Asymptotes: A Guide To Rational Functions

Hey guys! Let's dive into the world of rational functions and figure out how to graph those tricky asymptotes. Specifically, we're going to tackle the function $f(x) = \frac{-3x^2 - 1}{2x - 3}$. Understanding asymptotes is super important when you're working with rational functions, as they give you a clear picture of the function's behavior. Think of them as invisible lines that the graph gets super close to, but never quite touches. There are two main types of asymptotes we'll be looking at: vertical asymptotes and horizontal asymptotes (or sometimes, slant/oblique asymptotes). Don't worry, we'll break it all down step by step, so you'll be a pro in no time.

First off, vertical asymptotes. These are the vertical lines where the function shoots off to positive or negative infinity. They occur where the denominator of the rational function equals zero, and the numerator doesn't. This is where the function is undefined. Finding these is usually the easiest part. Let's start with our example function, $f(x) = \frac{-3x^2 - 1}{2x - 3}$. To find the vertical asymptotes, we need to set the denominator equal to zero and solve for x: $2x - 3 = 0$. Adding 3 to both sides gives us $2x = 3$. Then, dividing both sides by 2, we get $x = \frac{3}{2}$. This means there's a vertical asymptote at $x = \frac{3}{2}$. Cool, right? It's like a warning sign for our graph, telling us the function can't exist at that specific x-value. So, when you graph this, you'll draw a dashed vertical line at $x = \frac{3}{2}$. The function's graph will get closer and closer to this line, but never cross it. Think of it like an invisible barrier!

Next up, horizontal asymptotes. These are the horizontal lines that the function approaches as x goes to positive or negative infinity. Determining these can be a little trickier, but there's a simple rule based on the degrees of the numerator and denominator. The degree is the highest power of x in the polynomial. There are three cases to consider:

1. If the degree of the numerator is less than the degree of the denominator: Then the horizontal asymptote is always at $y = 0$. Imagine the numerator is growing slower than the denominator, so as x gets super big, the fraction gets closer and closer to zero.
2. If the degree of the numerator is equal to the degree of the denominator: Then the horizontal asymptote is at $y = \frac{a}{b}$, where a is the leading coefficient of the numerator and b is the leading coefficient of the denominator. Basically, you're looking at the ratio of the coefficients of the highest-powered x terms.
3. If the degree of the numerator is greater than the degree of the denominator: Then there is no horizontal asymptote. Instead, there might be a slant or oblique asymptote. We'll get to that later. In this case, the numerator is growing faster than the denominator, so the function doesn't level off; it keeps going.

In our example, $f(x) = \frac{-3x^2 - 1}{2x - 3}$, the degree of the numerator (2) is greater than the degree of the denominator (1). So, there is no horizontal asymptote. We'll have to see if there's a slant asymptote. Hold on tight, we're not done yet!

Finding Slant/Oblique Asymptotes

Okay, so what happens when there's no horizontal asymptote? That's where slant or oblique asymptotes come into play. These are straight lines that are neither horizontal nor vertical. They occur when the degree of the numerator is exactly one greater than the degree of the denominator. To find the equation of the slant asymptote, you need to perform polynomial long division.

Let's do it! We'll divide the numerator, $-3x^2 - 1$, by the denominator, $2x - 3$. Here's how it works:

1. Set up the long division:

       ___________
   2x - 3 | -3x^2 + 0x - 1


   • Notice that I've included a 0x term in the numerator. This helps keep things organized. You can also see that the numerator and denominator are arranged from highest to lowest degree.

2. Divide the leading terms:

   • Divide $-3x^2$ by $2x$. This gives you $-\frac{3}{2}x$. Write this above the line.

           -3/2 x
       ___________
   2x - 3 | -3x^2 + 0x - 1


3. Multiply and subtract:

   • Multiply $-\frac{3}{2}x$ by $(2x - 3)$, which gives you $-3x^2 + \frac{9}{2}x$. Write this below the terms in the numerator.

           -3/2 x
       ___________
   2x - 3 | -3x^2 + 0x - 1
           -3x^2 + 9/2 x


   • Subtract this from the numerator. Remember to change the signs!

           -3/2 x
       ___________
   2x - 3 | -3x^2 + 0x - 1
           -3x^2 + 9/2 x
           _________
                 -9/2 x - 1


4. Bring down the next term:

   • Bring down the -1.

           -3/2 x
       ___________
   2x - 3 | -3x^2 + 0x - 1
           -3x^2 + 9/2 x
           _________
                 -9/2 x - 1


5. Repeat:

   • Divide $-9/2 x$ by $2x$. This gives you $-\frac{9}{4}$. Write this above the line.

           -3/2 x - 9/4
       ___________
   2x - 3 | -3x^2 + 0x - 1
           -3x^2 + 9/2 x
           _________
                 -9/2 x - 1


   • Multiply $-\frac{9}{4}$ by $(2x - 3)$, which gives you $-\frac{9}{2}x + \frac{27}{4}$. Write this below the $-9/2x - 1$.

           -3/2 x - 9/4
       ___________
   2x - 3 | -3x^2 + 0x - 1
           -3x^2 + 9/2 x
           _________
                 -9/2 x - 1
                 -9/2 x + 27/4


   • Subtract, giving you a remainder of $-\frac{31}{4}$.

           -3/2 x - 9/4
       ___________
   2x - 3 | -3x^2 + 0x - 1
           -3x^2 + 9/2 x
           _________
                 -9/2 x - 1
                 -9/2 x + 27/4
                 _________
                       -31/4


The result of the long division is $-\frac{3}{2}x - \frac{9}{4}$ with a remainder of $-\frac{31}{4}$. The equation of the slant asymptote is given by the quotient (the result without the remainder), so our slant asymptote is $y = -\frac{3}{2}x - \frac{9}{4}$. The remainder is important for understanding the behavior of the function, but it's not needed for the equation of the slant asymptote.

So there you have it, folks! We've found the vertical asymptote ($x = \frac{3}{2}$) and the slant asymptote ($y = -\frac{3}{2}x - \frac{9}{4}$) for our rational function. You would graph the slant asymptote as you would any other line. Plot some points or use the slope-intercept form. As x approaches positive or negative infinity, the graph of the function will get closer and closer to this line. The vertical asymptote is a line the graph will never cross, but it can get arbitrarily close to.

Summarizing and Graphing

Let's quickly recap what we've learned and then put it all together to graph the function. Remember our function is $f(x) = \frac{-3x^2 - 1}{2x - 3}$.

1. Vertical Asymptote: Found by setting the denominator equal to zero and solving for x. We found $x = \frac{3}{2}$.
2. Horizontal Asymptote: Since the degree of the numerator (2) is greater than the degree of the denominator (1), there is no horizontal asymptote.
3. Slant Asymptote: Found by performing polynomial long division. We found $y = -\frac{3}{2}x - \frac{9}{4}$.

Now, to graph the function, here are the general steps:

1. Draw the asymptotes: Draw the vertical asymptote at $x = \frac{3}{2}$ as a dashed line. Draw the slant asymptote $y = -\frac{3}{2}x - \frac{9}{4}$ as a dashed line. Use the slope and y-intercept to make it simple.
2. Find the x-intercept(s): Set the numerator equal to zero and solve for x. In our case, $-3x^2 - 1 = 0$ gives us $-3x^2 = 1$, or $x^2 = -\frac{1}{3}$. This has no real solutions, which means there are no x-intercepts. If there were, you'd plot those points.
3. Find the y-intercept: Set x = 0 and solve for y. In our case, $f(0) = \frac{-3(0)^2 - 1}{2(0) - 3} = \frac{-1}{-3} = \frac{1}{3}$. So, plot the point $(0, \frac{1}{3})$.
4. Plot some additional points: Choose a few x-values on either side of the vertical asymptote (e.g., x = 0, 1, 2, 3) and calculate the corresponding y-values. Plot these points.
5. Sketch the curve: Using the asymptotes as guides, sketch the curve of the function. Remember that the curve should approach the asymptotes but not cross the vertical one (unless there is a hole in the function, which we do not have here). The behavior of the function depends on the asymptotes and intercepts you found.

By following these steps, you'll be able to accurately graph the function. Remember that asymptotes are critical features to understand. They reveal the behavior of the graph as x approaches certain values. Keep practicing, and you'll get the hang of it! Good luck, and happy graphing, everyone!
