Ellipse Equation And Graphing A Step By Step Solution

In the realm of conic sections, the ellipse stands out as a captivating geometric shape, possessing a unique blend of symmetry and curvature. Understanding the properties and equations of ellipses is crucial in various fields, ranging from astronomy (where planetary orbits are elliptical) to engineering (where elliptical gears are used). This article delves into the process of finding the equation of an ellipse given its vertices and focus, and subsequently sketching its graph. We will use the specific example of an ellipse with vertices at (-2.5, 0) and (2.5, 0) and a focus at (1.5, 0) to illustrate the step-by-step procedure. By the end of this guide, you will be equipped with the knowledge and skills to confidently tackle similar problems involving ellipses.

Understanding the Ellipse

Before we dive into the calculations, let's establish a solid understanding of the fundamental properties of an ellipse. An ellipse is defined as the set of all points in a plane such that the sum of the distances from two fixed points, called the foci (plural of focus), is constant. This constant sum is equal to the length of the major axis, which is the longest diameter of the ellipse. The midpoint of the major axis is the center of the ellipse.

The vertices of an ellipse are the endpoints of the major axis. The distance from the center to a vertex is denoted by 'a', and this is known as the semi-major axis. The minor axis is the shortest diameter of the ellipse, and it is perpendicular to the major axis. The distance from the center to an endpoint of the minor axis is denoted by 'b', and this is known as the semi-minor axis. The distance from the center to a focus is denoted by 'c'. These parameters (a, b, and c) are related by the equation:

c² = a² - b²

This equation is a cornerstone in determining the shape and dimensions of an ellipse. It highlights the relationship between the distances from the center to the foci and the lengths of the semi-major and semi-minor axes. Understanding this relationship is crucial for accurately sketching the ellipse and deriving its equation.

Step 1: Identifying the Center and Semi-Major Axis

Our initial task is to determine the center of the ellipse and the length of its semi-major axis. We are given the vertices as (-2.5, 0) and (2.5, 0). The center of the ellipse is the midpoint of the line segment connecting the vertices. We can find the midpoint using the midpoint formula:

Center = ( (x₁ + x₂) / 2 , (y₁ + y₂) / 2 )

Plugging in the coordinates of the vertices, we get:

Center = ( (-2.5 + 2.5) / 2 , (0 + 0) / 2 ) = (0, 0)

Therefore, the center of the ellipse is at the origin (0, 0). This simplifies our calculations significantly, as it means the ellipse is centered around the origin of the coordinate plane.

The semi-major axis, 'a', is the distance from the center to a vertex. Since the center is (0, 0) and a vertex is (2.5, 0), the distance between them is 2.5 units. Thus:

a = 2.5

We now know that the semi-major axis has a length of 2.5 units. This information will be crucial in determining the equation of the ellipse and sketching its graph. The vertices lie on the major axis, and since they have the same y-coordinate (0), we can conclude that the major axis is horizontal.

Step 2: Finding the Distance to the Focus and Semi-Minor Axis

Next, we need to determine the distance from the center to the focus, which we denote as 'c', and subsequently calculate the length of the semi-minor axis, 'b'. We are given that the focus is at (1.5, 0). The distance from the center (0, 0) to the focus (1.5, 0) is 1.5 units. Therefore:

c = 1.5

Now that we have 'a' and 'c', we can use the relationship c² = a² - b² to find 'b'. Substituting the values we have:

(1.5)² = (2.5)² - b²

2. 25 = 6.25 - b²

b² = 6.25 - 2.25

b² = 4

b = √4 = 2

So, the semi-minor axis, 'b', has a length of 2 units. This completes our calculation of the key parameters of the ellipse. We now know the lengths of both the semi-major and semi-minor axes, as well as the distance from the center to the focus. This information is sufficient to write the equation of the ellipse and sketch its graph.

Step 3: Determining the Equation of the Ellipse

With the values of 'a' and 'b' determined, we can now write the equation of the ellipse. Since the center is at the origin (0, 0) and the major axis is horizontal, the standard form of the equation of the ellipse is:

x² / a² + y² / b² = 1

Substituting the values a = 2.5 and b = 2, we get:

x² / (2.5)² + y² / (2)² = 1

x² / 6.25 + y² / 4 = 1

To eliminate the decimal, we can multiply the entire equation by the least common multiple of 6.25 and 4, which is 25:

(25)( x² / 6.25 + y² / 4 ) = (25)(1)

4x² + 6.25y² = 25

Thus, the equation of the ellipse is:

4x² + 6.25y² = 25

This equation encapsulates the geometric properties of the ellipse, defining the relationship between the x and y coordinates of any point on the ellipse. It is a concise mathematical representation of the shape and dimensions of the ellipse. This equation is crucial for various applications, including plotting the ellipse and solving related problems.

Step 4: Sketching the Graph of the Ellipse

Now that we have the equation of the ellipse, we can sketch its graph. We know the center is at (0, 0), the vertices are at (-2.5, 0) and (2.5, 0), and the foci are at (-1.5, 0) and (1.5, 0). We also know that the semi-major axis is 2.5 units and the semi-minor axis is 2 units.

1. Plot the Center: Start by plotting the center of the ellipse at (0, 0). This will serve as the reference point for drawing the ellipse.
2. Plot the Vertices: Plot the vertices at (-2.5, 0) and (2.5, 0). These are the endpoints of the major axis and will define the extent of the ellipse along the x-axis.
3. Plot the Foci: Plot the foci at (-1.5, 0) and (1.5, 0). These points are crucial for understanding the shape and curvature of the ellipse. The closer the foci are to the center, the more circular the ellipse becomes.
4. Determine the Endpoints of the Minor Axis: Since the semi-minor axis is 2 units, the endpoints of the minor axis will be 2 units above and below the center. Therefore, the endpoints are (0, 2) and (0, -2).
5. Sketch the Ellipse: Now, sketch the ellipse by drawing a smooth curve that passes through the vertices and the endpoints of the minor axis. The ellipse should be symmetrical about both the major and minor axes. The shape of the ellipse will be determined by the relative lengths of the major and minor axes.

By following these steps, you can create an accurate sketch of the ellipse. The graph visually represents the equation we derived earlier and provides a comprehensive understanding of the ellipse's shape and position in the coordinate plane.

Conclusion

In this article, we have walked through the process of finding the equation of an ellipse given its vertices and focus, and subsequently sketching its graph. We used the example of an ellipse with vertices at (-2.5, 0) and (2.5, 0) and a focus at (1.5, 0) to illustrate the steps involved. We first identified the center and semi-major axis, then calculated the distance to the focus and the semi-minor axis. Using these values, we derived the equation of the ellipse and finally sketched its graph.

The key takeaways from this guide are:

• The center of the ellipse is the midpoint of the vertices.
• The semi-major axis (a) is the distance from the center to a vertex.
• The distance from the center to the focus (c) is related to 'a' and the semi-minor axis (b) by the equation c² = a² - b².
• The standard form of the equation of an ellipse with a horizontal major axis and center at the origin is x² / a² + y² / b² = 1.

By mastering these concepts and practicing similar problems, you will develop a strong understanding of ellipses and their applications in various fields. The ability to find the equation and sketch the graph of an ellipse is a valuable skill in mathematics, physics, and engineering. This article serves as a comprehensive guide to help you achieve that mastery. Remember to always start by identifying the key parameters of the ellipse, such as the center, vertices, and foci, and then use these parameters to derive the equation and sketch the graph. With practice, you will become proficient in working with ellipses and solving related problems with confidence.
